SMT PCB Production Line
Pcb Assembly Line Pick And Place Machine
Pcb Assembly Line Pick And Place Machine
Pcb Assembly Line Pick And Place Machine
The Pick and Place Machine puts components on boards quick as a wink and dead accurate.
a. Tops out at 100,000 parts an hour.
b. Handles chips smaller than a grain of rice.
c. Holds up to 112 feeders easy.
d. Slim build fits tight factory floors.
e. Sharp cameras keep every part straight.
f. IST sets up whole lines smooth.
g. Solid backup keeps everything humming.
Model: SX-T2808
Brand: IST
Pick And Place Assembly Machine
Well now, if you’re running a modern electronics shop, you need a machine that works fast and doesn’t fuss. This Pick and Place Machine from IST does just that. It grabs tiny chips and bigger parts alike and sets them down exactly where they belong on the circuit board. The whole setup is modular, so you can add pieces as your business grows. Cameras watch every move in real time. Programming is straightforward—no headaches there. The narrow frame slides right into crowded lines. IST handles everything from planning to daily care. Factories making car parts or lights turn out more good boards with less trouble. It’s plain good sense for busy plants.
These two are the flexible kind. The SX-T2808 pushes 47,000 parts per hour with placement true to ±35µm. It takes boards up to 650×370mm, and the RS-1XL stretches that to 650×560mm for bigger jobs like lighting panels. The Takumi head shifts on the go to handle odd shapes and mixed runs. You get room for 112 feeders, so switching products doesn’t slow you down. Vision spots bad marks quick, and gentle force keeps delicate boards safe. They team up fine with high-speed models for all kinds of work. Changeovers happen smooth, and output stays steady.
Here’s where raw speed lives. The SX-T2808 hits 75,000 per hour, while the RX-8 climbs clear to 100,000 using that clever P20 head. Both stay skinny at 998mm wide so they don’t hog floor space. They place chips as small as 03015 without blinking. Parallel heads work together like a well-oiled team. New lighting makes tiny parts show up clear as day. Soft-touch mode protects fragile pieces. Machines talk to each other, sharing marks and stock levels. You get more parts out per square foot than just about anything else. Perfect for high-volume small-chip runs in phones or drivers.
Parameter | SX-T2808 | SX-T2812 |
Placement Speed (Optimum CPH) | 47,000 | 42,000 |
Maximum Board Size (mm) | 1500 | 1500 |
Minimum Board Size (mm) | 1350 | 1350 |
Component Height (max mm) | 26 | 26 |
Smallest Component | 0201 (metric) | 0201 (metric) |
Largest Component (mm) | 74 square / 150×50 | 74 square / 150×50 |
Feeder Inputs (max) | 112 | 112 |
Placement Accuracy | ±35µm (Cpk ≥1) | ±35µm (Cpk ≥1) |
Machine Width (mm) | 1,500 (approx.) | 2,109 |
Head Type | Takumi inline head | Takumi inline head |
Specification
SMT Line Equipment List
SMT LINE
IST builds lines that really deliver. Vacuum loader brings boards in spotless. Printer spreads paste even every time. The Pick and Place Machine drops each chip right on target. Multi-zone reflow locks solder down solid. AOI catches any slip before it goes further. Conveyors link everything tight with buffers to keep flow steady. Yield goes way up, costs come down. No weak spots anywhere. These lines handle tough automotive power jobs and lighting work day in and day out. Boards leave ready for the real world, and we stand behind the whole thing from start to finish.
Product Name | Purpose in SMT Line |
Ful-Auto SMT Production Line for Automotive, LED etc | |
Automatically loads bare PCBs to the line. | |
Prints solder paste on PCB pads accurately. | |
Mounts components onto PCBs precisely. | |
Melts solder to form solid joints. | |
Inspects solder joints and placement defects. | |
Checks solder paste height and quality. |
Service and Training Support
When you buy a Pick and Place Machine, IST doesn’t just ship it and walk away. Our crew comes out, sets it up, and runs tests until it’s perfect. Training is practical—operators learn programming, daily care, and fast fixes right on the floor. Remote links let us solve problems quick from afar. Regular service plans keep machines sharp for years. We look over whole lines and suggest smarter ways to run them. Upgrades fit easy. With offices all over the map, help shows up fast no matter where you are. Customers keep producing without long breaks.
Customer Feedback
Folks who run these lines talk plain. They like how our engineers show up prepared and get things fixed quick. The Pick and Place Machine earns praise for steady speed and rare mistakes. Packing is careful—machines arrive safe every time. Questions get answered fast, usually same day. Support feels close even halfway around the world. Lines stay up longer, numbers climb higher. Overall, buyers say the machines plus the people behind them add real value to every shift.
Certifications and Standards
Every Pick and Place Machine carries solid proof of quality. CE mark means it meets tough European safety rules. RoHS shows no harmful stuff inside. ISO9001 keeps quality steady from drawing board to shipping dock. Plenty of patents cover the smart heads and vision tricks. These stamps tell customers the equipment is safe for workers, easy on the environment, and built to work hard for years. You can buy knowing it meets world standards straight up.
