IST-auto SMT SMD Production Line

a. Full automatic process flow.

b. JUKI high-speed placement.

c. Quick installation in 3 days.

d. Low power use at 18Kw/H.

e. Global after-sales support.

f. Training in 7-15 days.

g. Semi-auto options available.

SMT Production Line Solution

IST offers complete SMT Production Line from planning to full operation. We design semi-auto and full-auto lines with JUKI machines for surface mounting. Our team has 22 years in SMT technology and supports many factories. Lines include loader, printer, JUKI pick-and-place, reflow oven, AOI, and unloader. Full-auto setup needs one worker per shift and runs smoothly every day. Power is 18Kw/H for large lines to save energy costs. We serve LED, TV, phone, auto, and other industries worldwide. Installation takes 3 days with expert team setup. Training lasts 7-15 days to teach your staff fully. We help build or upgrade factories globally with professional advice and custom plans. This turnkey solution makes starting easy and fast for new makers. Semi-auto SMT Production Line suits small production well.

Category	Projects	Details
Factory Layout Requirements	Factory Air Circuit Layout	Use factory air source or separate oil-free compressed air machine. Pressure should be greater than 7kg/cm².
	Factory Electrical Layout	Single-phase AC220 (220±10%, 50/60Hz) Three-phase AC 380V (380±10%, 50/60Hz)
	Factory Exhaust Layout	The minimum flow rate of the exhaust duct is 500 cubic feet per minute (14.15m³/min)
	Factory Lighting Layout	The ideal illumination in the factory is 800~1200LUX, at least not less than 300LUX.
	Factory Temperature Layout	The ambient temperature of the production workshop is 23±3°C, generally 17~28°C, and the relative humidity is 45%~70%RH.
Material Preparation	BOM List	List all parts and quantities needed for PCBA Production Line assembly.
	CAD File	Digital design file to plan PCB layout and machine setup.
	Gerber File	Standard file for PCB manufacturing and printing stencil.
	Solder Paste	Material applied on pads before placing components in printer.
	SMD Component Materials	Surface mount parts like chips and resistors for placement.
	Industrial Alcohol	Used to clean boards and stencils during setup process.
	Splice Belt	Tape to connect feeder reels without stopping the line.
	Stencil	Metal sheet with holes to print solder paste accurately.
